Sequential Take 5

Take 5 specifications

Oscillators:

Two analogue VCOs per voice

Infinitely crossfadeable waveforms (sine, sawtooth, variable pulse width) per oscillator

Hard sync: oscillator 1 synchronises with oscillator 2

Square wave sub-oscillator (oscillator 1) per voice

Switchable keyboard tracking per oscillator

FM (frequency modulation) directly via the control panel

Mixer:

Amount/proportion oscillator 1

Amount/share sub-octave oscillator 1

Amount/share oscillator 2

Amount/share white/pink noise

Low-pass filter:

Four-pole, resonant low-pass filter per voice, based on the design of the Prophet-5 Rev 4

The filter can be set to self-oscillate using the resonance control

Bipolar intensity control for the envelope generator

Envelopes:

Two five-stage envelope generators (ADSR + delay) with variable routing (filter, amplifier, AUX)

Modulation of the stroke of each envelope via the velocity response

The envelopes can be freely assigned to multiple modulation destinations

LFO:

Five waveforms: Triangle, sawtooth, inverted sawtooth, square and random (sample and hold)

Clock synchronisation (internal or to an external MIDI clock)

Free assignment to multiple modulation destinations

Digital effects:

A dedicated reverb with adjustable attenuation, pre-delay, decay time and timbre

A multi-effect with stereo delay, BBD delay, tape delay, chorus, flanger, phaser, ring modulation, vintage rotary speaker, distortion, high-pass filter

Dedicated overdrive effect

Vintage control:

Emulates the characteristics of vintage synthesizers through parameter variations from voice to voice.

Aftertouch:

Source: Channel aftertouch (mono) with bipolar intensity control

Aftertouch can be freely assigned to multiple modulation destinations

Clock:

Master clock with tap tempo

BPM control and display

MIDI clock synchronisation

Arpeggiator:

Operating modes: up, down, oscillate, random, assignable

Synchronisation to MIDI clock

Relatch function while arpeggio is running

Sequencer:

Polyphonic step sequencer with up to 64 steps and support for tied notes and rests

Performance controller:

Full-format, semi-weighted 3.5-octave premium keyboard from Fatar with velocity sensitivity and aftertouch

Pitch wheel with centring spring and independently selectable up and down range for transposition per programme.

The low-split mode creates two independent performance ranges with different octave ranges

Hold button locks played notes

Polyphonic glide (portamento)

Unison mode (monophonic) with configurable number of voices, from one to all five voices, and several playing modes

Factory button: When switched off, the control panel is active. Here you can hear exactly the sound that corresponds to the current settings of the controls.

Programme memory:

128 user-definable and 128 factory sounds

Connections:

1 x MIDI In, 1 x MIDI Out, 1 x MIDI Thru

USB port for bidirectional MIDI communication

1 sustain pedal/foot switch input

1 expression pedal input

Main stereo output (2 x 6.5 mm jack socket)

Headphone output (6.5 mm stereo jack socket)

Power supply:

IEC AC input for the internal power supply unit

Can be operated worldwide with voltages from 100 to 240 volts at 50 to 60 Hz; maximum power consumption of 14 watts

Physical specifications:

High-quality, semi-weighted Fatar keyboard with 3.5 octaves

Dimensions: L x W x H (63.5 cm x 32.4 cm x 11.2 cm)

Weight: 7.7 kg
