Oberheim TEO-5 modules
€1,229.00
Prices incl. VAT plus shipping costs
(Free shipping from 49,-€ order value within Germany)
Weitere Informationen finden sie hier.
Expected to be available from 07.08.2025
Technical data:
5-voice VCO/VCF polysynth
Two VCOs + sub-oscillator per voice
Selectable waveforms: Triangle, sawtooth, pulse
Hard sync between oscillators
Through-Zero FM via X-Mod control
Switchable key tracking per oscillator
White noise in the mixer
SEM filter with morphable state control
Stepless filter mode: lowpass - notch - highpass
Bipolar filter envelope assignment
Velocity control for filter envelope
Keyboard tracking in the filter
Two DADSR envelope generators
Velocity modulation for amp and filter envelope
Freely assignable modulation destinations
Two LFOs with five waveforms
LFO sync to clock
Initial Amount for LFOs
Vintage control for voice-dependent fluctuations
Channel aftertouch with bipolar modulation
Freely modulatable aftertouch
Master clock with tap tempo
BPM display and control
MIDI clock sync
Arpeggiator with multiple note values and octave ranges
Arp modes: Up, Down, Up/Down, Random, Assign
64-step sequencer with ties and pauses
Reverb with damping, pre-delay, decay, tone
Multi-effect: delay, chorus, flanger, phaser, ring mod, distortion, rotary, etc.
Separate overdrive effect
Hold function for notes
Polyphonic glide (portamento)
Unison mode with up to 5 voices and priority modes
Manual mode: controls correspond directly to the sound
256 user and 256 factory sounds
Direct access to programmes with one button
Dimensions: 53.3 x 17.8 x 8.9 cm
Weight: 3.08 kg
Connections:
Stereo audio outputs (2x 6.35 mm jack)
Stereo headphone output (6.35 mm jack)
MIDI In / Out / Thru
USB for bidirectional MIDI
Input for expression pedal
Input for sustain pedal
IEC power connection
Properties
| Polyphony: | 5 |
|---|---|
| Sound generation: | Analogue |
Contact:
FOCUSRITE GROUP EMEA LIMITED
Rudower Chaussee 50
12489 Berlin
E-Mail: compliance@focusritegroup.com
Web: https://focusrite.com/
Oberheim Electronics is a legendary manufacturer of synthesizers and music equipment founded by Tom Oberheim in 1969. Known for its groundbreaking analogue synthesizers, Oberheim has had a decisive influence on the development of electronic music. The brand gained particular fame in the 1970s and 1980s with iconic models such as the OB-X, OB-8 and Matrix-12, which are prized for their warm sound and versatile programming options. Oberheim products are not only popular with musicians, but also with producers and composers who utilise the characteristic sound of the devices in their work. With a combination of traditional craftsmanship and innovative design, Oberheim remains a major player in the world of synthesisers, inspiring generations of musicians.
