KS CPD 1
€3,238.83*
Prices incl. VAT plus shipping costs
Weitere Informationen finden sie hier.
Delivery on request
Unique dispersion behaviour due to HDSP tweeter horn
PWM power amplifier (woofer) in combination with analogue FET technology (tweeter)
2-way DSP controller with FIR filters - low-feedback and implustrue
Switchable delay and high-pass filter
Peak power 1kW
Frequency range: 68-19000Hz +-3dB
Power: 440W rms
Max. Sound pressure: 134dB (peak)
Beam angle: asymmetric 60°-120°/35°
Frequency response: 1500Hz
Speaker: 10"-cone ND, 1"-driver ND
Amplifier: PWM + bipolar bridge
Mains connection: PowerCon 117/230VAC
Dimensions (WxDxH): 298x330x516mm
Weight: 20kg
The CPD 1 complements the KS CPD series of active self-powered systems with its special HDSP dispersion behaviour - with minimal dimensions and weight. The sound pressure level is exceptionally high and even right down to the bass range. The DSP controller works with FIR filter technology for absolutely faithful impulse reproduction. Two integrated amplifiers provide the 10" chassis with 400W and the 1" driver with 40W of power - the peak output is 800W.
Properties
| Power in watts: | 440 W (RMS) |
|---|---|
| Woofer in inches: | 10 |
