JB-Lighting A12 RGBW
€5,421.33
Prices incl. VAT plus shipping costs
(Free shipping from 49,-€ order value within Germany)
Delivery on request
Optics and light source:
Zoom system 4° - 48° (4°-33° 1/2 peak, 8°-48° 1/10 peak)
Highly efficient lens system
61 RGBW multichip LEDs in the 15W class
Hexagonal lens shape for homogeneous light emission
Effects:
450° pan / 330° tilt
Separate CTC channel
Optimised colour mixing behaviour thanks to multichip LEDs, combined with extremely narrow LED spacing
High-resolution, stepless dimmer 0% - 100%
Colour fidelity dimming
Electronic strobe with pulse and random effects
LED segment control for ring effects
Drive:
High-resolution 3-phase stepper motors
Precise and fast movements
Quiet, suitable for noise-sensitive applications
Control:
DMX-512
Integrated receiver for JB-lighting wireless DMX
Illuminated graphic display, electronically rotatable
Stand-alone mode
Power consumption:
Max. 830W
Typical consumption: 490W
Construction:
Compact housing
Powercon In and Out
3-pin and 5-pin XLR connections
Temperature-controlled fans
Omega bracket for quick and convenient mounting in any position
Dimensions: W 437 x D 308 x H 536mm
Weight: 15.7kg
Accessories:
Wireless TRX
2-fold flight case
A total of 61 RGBW multichip LEDs in the 15W class are used in the A12 in a newly developed optical zoom system. Thanks to the hexagonal lenses, the light field appears absolutely homogeneous, almost like a single light source. The A12 has enormous brightness and, depending on the colour, replaces a 1200W to 1500W washlight with discharge lamp. The zoom range covers a remarkable 4° - 48°.
As with previous LED washers from JB-lighting, the A12 is also characterised by sophisticated software. Particular attention was paid to the dimming behaviour, which enables the A12 to dim with the highest resolution and absolute colour fidelity. Various control curves for RGBW are available for demanding work, as well as different dimming curves and camera modes that guarantee flicker-free work in television studios. Naturally, the A12 is equipped with low-noise 3-phase stepper motors and, like the A4, A7 and A8, has a factory-installed receiver module for JB-lighting Wireless DMX.
The A12 is designed for large stages and applications where a powerful spotlight is required. It easily replaces a washlight with a 1200W discharge lamp and is the only multi-chip LED washlight capable of achieving extremely narrow beams.
