Appsys Multiverter MVR-64
€2,715.03*
Prices incl. VAT plus shipping costs
Weitere Informationen finden sie hier.
Delivery on request
Digital multi-format converter and splitter:
Audio interfaces:
- ADAT (8x)
- MADI optical
- MADI coaxial
- MADI-TP (max. 2 ports)
- AES50 (max. 2 ports)
- Dante/AES67 (2 ports/integrated switch)
- Expansion interface
Clocking options:
- Sample rates from 32...192 kHz
- Word clock input/output (BNC)
- Each interface can be used as a master clock.
Alternatively, a high-quality internal reference clock is available
- Supports MADI 96k frame and SMUX operation
Remote control:
- MIDI
- MIDI via MADI
- USB
- RS485 (compatible with Yamaha Headamp Remote Control)
- AES50 Aux Data Channel (compatible with Behringer S16)
- Network (Telnet/Socket)
Miscellaneous:
- Preset Store/Recall (12 different presets)
- Headphone amplifier: Each input signal/channel can be monitored
- Test tone generator for easy troubleshooting in complex setups
- Triple redundant power supply (2x 90-240VAC, 1x 9-18VDC)
- Can be operated independently of the mains from a camera battery pack (4-pin XLR connector)
The plus:
Recording of any signal source
Universal interface in the OB van
64x64 channel PC interface via Dante® Virtual Soundcard
Operation of Yamaha® consoles with inexpensive Behringer® or MIDAS® stageboxes or vice versa
(integrated adapter for preamp control*)
Low-latency transmission of 64x64 audio channels via normal Ethernet network
Integration of "legacy" devices
The Appsys "Multiverter", the Swiss army knife for digital audio. This unique device converts between the digital formats ADAT, MADI optical, MADI coaxial, MADI-TP, AES50, Dante (and others via break-out boxes).
The multiverter has an integrated headphone amplifier and a test tone generator for simple system diagnostics. Three redundant power supplies (2xAC, 1xDC) allow uninterrupted operation under all conceivable circumstances - even battery operation. The device is prepared for remote control of various preamps (Yamaha, Behringer, MIDAS) and thus even allows the combination of mixing consoles and preamps from different manufacturers.
Contact: Appsys ProAudio Bullingerstr. 63, BK 241 CH - 8004 Zürich E-Mail: info@appsys.ch Web: http://www.appsys.ch
