Article-No 1140060

Warm Audio TB12-500

€561.62*

Prices incl. VAT plus shipping costs

Finanzieren Sie bequem mit Consors Finanz.
Weitere Informationen finden sie hier.

Cheaper elsewhere?

Delivery on request

Warm Audio TB12-500

1-channel microphone and instrument preamp in 312 style

requires 2 module slots in a 500 rack

71dB gain

The transformer bypass switch removes the output transformers from the signal chain

Steel and 50% nickel transformers for different sound shaping

Two different discrete OpAmps: 1731 (Vintage) and 918 (Cleaner)

TONE switch - switches the input impedance from 600 ohms to 150 ohms (sound change at both the microphone and instrument inputs)

Front Hi-Z input sends the signal through the entire circuit

Microphone input: XLR (front and rear), balanced 6.3mm jack

Instrument input: 6.3mm jack

Balanced outputs: XLR and 6.3mm jack

Insert: 6.3mm jack

48V phantom power

-20dB pad

Phase reverse switch

LoCut

LED metre

The Warm Audio Tone Beast TB12-500 is a single-channel microphone and instrument preamplifier in API 500 format. It is equipped with Cinemag input and output transformers (made in the USA), which already provide the appropriate signal quality in high-end devices such as the Presonus ADL-700, A-Designs Pacifica or Universal Audio LA-610.

The discrete circuitry of the TB12 is based on the familiar 312 design and has been enhanced with numerous features that make the Tone Beast a powerful and flexible sound shaping tool.

The preamp delivers up to 71dB gain. In addition to the microphone input (XLR), the equipment also includes a line input and an instrument input, both of which are available in the form of jack connections.

Warm Audio

Contact:

Sonic Sales GmbH
Liebigstr. 24
33803 Steinhagen

E-Mail: info@sonic-sales.de
Web: https://www.sonic-sales.de/
