TASCAM BD-MP4K

Process all popular video and audio formats with a single powerful player

As a professional-grade, remote-controlled 4K UHD Blu-ray player, the Tascam BD-MP4K is the perfect choice for a wide range of commercial installations that require ultra-high-definition picture quality. These include public institutions, educational establishments and commercial enterprises as well as theatres and other businesses in the amusement and entertainment business.

With only one height unit in the rack, the compact BD-MP4K saves space by eliminating the need for separate audio/video playback devices in an installation rack. It handles a wide range of media and file formats on discs (Blu-ray/DVD/CD), USB sticks, SD cards and SMB network shares on a NAS or remote server via Gigabit Ethernet.

Easy integration into media systems:

For integrated media systems where remote control beyond infrared is desired, the BD-MP4K offers both an RS-232C interface and an IP network connection. The RS-232C interface allows seamless and reliable communication between devices with status feedback, while Gigabit Ethernet simplifies integration into larger systems and thus the mutual control of components.

In addition to remote control operation, all playback functions can also be called up locally via the control panel if required. Separate locking functions for the control panel, disc tray and IR remote control prevent accidental changes or unauthorised use if required.

Screens or televisions can be connected quickly and easily via two plug-and-play HDMI connections on the rear, which support both HDMI 2.0 and HDMI 1.4 (audio only) formats.

Typical Tascam: A little bit more of everything

When it comes to professional sound quality and integration into commercial environments, the BD-MP4K is a thoroughbred Tascam product. The rear panel features individual connections for 7.1 surround sound, enabling absolutely realistic and detailed sound reproduction in any installation. Professional balanced stereo analogue outputs via XLR connectors and unbalanced RCA stereo outputs are also available. And a coaxial output delivers professional-quality digital audio formats, including Dolby, DTS and two-channel linear PCM (SPDIF).

With its high picture resolution and outstanding audio quality, support for virtually all common media and file formats and comprehensive connectivity and configuration options, the BD-MP4K fulfils even the highest demands, making it the ideal choice for professional use in fixed installations or on tour.

The versatile BD-MP4K supports a wide range of media formats, including Blu-ray, DVD and CD, as well as files on USB sticks, SD cards and network shares. This makes individual devices for the respective audio and video formats in an installation

superfluous. The many supported file formats include:

Video formats such as 3GP, ASF, AVI, DAT, M2TS, MKV, WMV, MOV, MP4, MPG, OGM, TP, TS,

Image formats such as JPEG, GIF and PNG and

The audio formats AAC, APE, FLAC, MP3, WAV and WMA

Connections for external media: An SDXC slot on the front and a USB 3.0 port on the back enable permanent or alternating access to external media

Professional functions:

Start playback on power and repeat function: Thanks to its automatic switch-on function, the BD-MP4K is able to start playback as soon as it is supplied with power. If the repeat function is activated at the same time, the device automatically starts playback and continues it in an endless loop until the power supply is disconnected again. In fixed installations, this means that by switching on the integrated AV system once, announcements, commercials or other content will play in a loop without having to press a button on the device itself

Control panel lock for secure operation: Lock functions for the control panel and disc tray allow you to protect the device from accidental setting changes or unauthorised use. In addition, you can prevent control via the infrared remote control, for example to prevent preset parameters from being changed in a commercial environment and thus ensure consistently reliable operation in any media system

Elegant switch-on sequence on the display: The monitor display can be set so that a black screen appears at the start instead of the manufacturer's start page with menu items. This creates a much more elegant visual impression when the system is switched on

Two HDMI outputs for projectors, screens and sound systems: You can easily and reliably connect any HDMI-compatible monitor, projector or TV to the standard HDMI output via plug-and-play. This output also supports HDMI CEC. This ensures that the connected display is switched on and off in the correct order

Balanced and unbalanced analogue outputs: With professional balanced XLR outputs as well as unbalanced RCA outputs, the BD-MP4K offers various options for routing, connection and setup, underlining its appeal for commercial installation environments

Coaxial digital audio output: The BD-MP4K can output professional digital audio formats such as Dolby, DTS and others via its coaxial output on the rear panel. It also supports output in two-channel LPCM format

Prepared for 7.1 surround systems: Separate outputs for 7.1 surround sound are available for impressive and rich audio playback in commercial audio systems. Use these outputs to feed a suitable surround amplifier or separate power amplifiers for larger rooms

Remote control via an Ethernet network and RS-232C: For more sophisticated audio/video setups, the BD-MP4K with RS-232C and Ethernet offers two professional options for bidirectional remote control with seamless, reliable feedback of the device status

The supplied infrared remote control allows easy operation of most functions and menus. Easily accessible control buttons on the front of the BD-MP4K provide access to the transport functions play, pause, stop and fast forward as well as menu navigation. The control panel can be locked if required, for example to prevent tampering by unauthorised persons.
