Article-No 1070440

Seeburg Acoustic Line G SUB 1501 dp

€2,698.00*

Prices incl. VAT plus shipping costs

Finanzieren Sie bequem mit Consors Finanz.
Weitere Informationen finden sie hier.

Delivery in 7-14 days

Seeburg Acoustic Line G SUB 1501 dp

single-channel amplifier electronics with DSP

Bass reflex cabinet

Equipment: 1x 15" neodymium woofer

Power: 1500 W AES (single mode), 2400 W AES (dual mode)

4 Ohm HiMid/Sub Class-D power amplifier with DSP controller

max. SPL: 135 dB

Frequency range: 35 - 100 / 120 / 140 Hz

DSP with DPLMx FPGA processing 32 bit floating point

4 presets

switchable cardioid preset

24 bit / 96 kHz AD/DA converter

Speaker Twist NL4 out

XLR in/out

Power Twist in/thru

Ethercon

2 carrying handles

M20 thread

compatible with Seeburg Networkmanager

Audio over IP according to AES 67

Housing material: Baltic birch multiplex with polyurea coating

Dimensions (W x D x H): 600 x 600 x 400 mm

Weight: 30.0 kg

Colour: Black


The G Sub 1501 dp is a multifunctional top-of-the-range subwoofer with integrated digital amplifier electronics with 2400 watts of power @ 4 ohms (AES) and DSP controller. The 15" long excursion neodymium chassis is driven by the built-in amplifier. In addition, a passive G Sub 1501 can be connected to a parallel output. Various factory-configured presets and volume settings can be called up.

The integrated DSP controller is based on the same principle as the external controllers HDLM 8 and DSP 2.6. The latency time of just 0.8 ms (between analogue input and output) is achieved by a sample rate of 96 kHz. Another feature that characterises the DSP controller is its very low background noise. By simulating a transformer-balanced input, the sensitivity to hum and surround noise (e.g. due to unfavourable current conditions) is also significantly minimised. High-quality electronic components from the industrial sector and a first-class circuit concept ensure high audio quality and overload resistance and effectively minimise interference noise.

The built-in DSP controller is in a standard configuration state ex works, which corresponds to the specifications in the user manual. The user can upload special presets to the

DSP Controller can be carried out by the user, as only a special preset audio file needs to be loaded. However, the creation of these audio files via the LPI (Loudspeaker Programming Interface) can only be carried out by the manufacturer. This means that customised settings can be programmed for installation projects, for example. If you are unsure about the DSP configuration, you can obtain the audio file with the factory presets from SEEBURG acoustic line. Highly effective and "intelligent" limiter systems ensure optimum protection against overloading without limiting the possibilities of this high-performance system.

Properties

Power in watts: 1500 W
Woofer in inches: 15
Acoustic Line

Contact:

Seeburg Acoustic Line GmbH
Auweg 32
89250 Senden

E-Mail: info@seeburg.net
Web: www.seeburg.net

0 of 0 reviews

Leave a review!

Share your experiences with other customers.
