RockBoard MOD 1 V2
€59.00*
Prices incl. VAT plus shipping costs
(Free shipping from 49,-€ order value within Germany)
In stock
All-in-one patchbay for pedalboards
suitable for MOD slots in RockBoard pedalboards
compatible with a wide range of other pedalboards
acts as a central access point to your effects setup
establishes clear cable routes to and from the pedalboard
removable front panel for mounting on or under pedalboards
5 x 6.3 mm TRS thru
1 x XLR thru (male front / female rear)
1 x DC 2.1 x 5.5 mm barrel thru
1 x AC IEC thru (male front / female back)
all connections mirrored on the rear
Dimensions excl. front panel (W x D x H): 160 x 60 x 33 mm
Dimensions of the front panel (W x H): 175 x 48 mm
Weight 450 g
incl. mounting screws, lock nuts and TX spanner
The revised RockBoard® MODs V2 are simple all-in-one patchbays for the RockBoard Pedalboard Series with a new, revised design and a compact housing. Suitable for all new RockBoards® (except the DUO series) with a MOD slot, they provide a convenient patchbay with various cable connections to cover a wide range of needs. With the RockBoard® MODs you can permanently wire your pedals under the board and organise all connections to and from your effects setup in one convenient module. The RockBoard® MODs provide a central access point from the instrument to the amp as well as a convenient and easy power supply to the board via an IEC and a 2.1 x 5.5 barrel-through power connector. The RockBoard® MOD 1 V2 is a pass-through box designed specifically for guitarists and bassists. You can use the MOD 1 V2 to position several pedals of your setup in the front end and effects loop of the amplifier (4-cable method) or use the four TRS connectors as the central input and output of the board. The XLR through connection can be used as a signal output from the pedalboard to the mixing console or PA.
