QSC LS118
€2,898.00
Prices incl. VAT plus shipping costs
(Free shipping from 49,-€ order value within Germany)
Delivery in 7-14 days
LF transducer: 460 mm (18 inch)
Frequency response (-6 dB): 41 Hz - 98 Hz
Frequency range (-10 dB): 35 Hz - 111 Hz
Maximum rated sound pressure 1 (peak): 136 dB at 1 m
Amplifier (peak): Class D, 4000 W
Cooling: Low-noise fan with variable speed
Controls: Rotary-push encoder, 2 x push buttons (menu, ID)
Display screen: 61 mm (2.4 inch) full-colour display area (240 x 320 pixels)
Indicators: Power LED, limiter active LED, standby active LED, 2 x signal LED
AC power input: Universal power supply 100-240 VAC, 50-60 Hz
AC power consumption 2: 100 VAC, 3.6 A / 120 VAC, 3.0 A / 230 VAC, 1.7 A
Housing material: 15 mm birch plywood with polyurea coating
1x XLR input
1x XLR output
2 x RJ45 EtherCON (Dante® and QSC SysNav™ In/Thru)
2 x PowerCON TRUE1 (AC power input/output)
8 x M10 (for individual vertical or horizontal suspension/flight mounting)
2 x M20 (for vertical or horizontal speaker mast or ground stack installation)
Colour: Black (RAL 9011)
Dimensions (HxWxD): 640 × 520 × 790 mm
Weight: 50 kg
The LS118 is an active subwoofer with innovative technology and a precise, high-quality design that is extremely easy to install and operate.
The intelligent speaker system contains only high-quality components and offers outstanding audio quality and exceptional performance. When developing the LS118, we paid particular attention to the requirements and areas of application of our customers.
Thanks to its simple configuration and installation, the LS118 is suitable for a wide range of applications - from simple, mobile setups requiring plug-and-play set-up to sophisticated, high-tech networked AV productions and fixed installations.
The QSC Acoustic Linear Phase (ALP) design allows the LS118 to be easily combined with other QSC loudspeakers in a phase-coherent manner and supports the loop-through of analogue or digital audio (Dante®) as well as the power supply (powerCON TRUE1). Two or more LS118s can be used in a cardioid arrangement to boost the bass output to the front and to optimise
the front and reduce the sound emitted to the rear and sides.
Together with the LA108 or LA112 active line array speakers, the LS118 can be mounted either with an array frame/ground stack adapter or using speaker poles in both horizontal and vertical orientations. The LS118 is covered by a worldwide, extended 6-year warranty after product registration.
Properties
| Power in watts: | 4000 W |
|---|---|
| Woofer in inches: | 18 |
