Oberheim TEO-5
€1,599.00
Prices incl. VAT plus shipping costs
(Free shipping from 49,-€ order value within Germany)
Weitere Informationen finden sie hier.
In stock
Oscillators:
5-voice VCO/VCF-based polysynth
2 VCOs and sub-oscillator per voice
Selectable waveforms for each oscillator: triangle, sawtooth, variable pulse
Oscillator 1 is synchronised with oscillator 2
Dedicated X-Mod control on the front panel
Switchable key tracking per oscillator
White noise generator accessible in the pre-filter mixer
Filter:
Variable SEM filter with selectable band-pass mode
State control changes continuously from low-pass to notch to high-pass
Bi-polar filter envelope value
Velocity modulation of the envelope
Keyboard tracking
Filter envelope:
Five-stage (DADSR) envelope generator
Velocity modulation of the envelope amount
AMP envelope
Five-stage (DADSR) envelope generator
Velocity modulation of the envelope
LFOs:
Five waveforms: Triangle, sawtooth, inverted sawtooth, square and random (sample and hold)
LFO tempo synchronisation
Initial Amount setting
Freely assignable mod destinations
Vintage Knob:
Recreates vintage synthesizer characteristics by adding variations in the behaviour of the components from voice to voice
Keyboard:
High-quality, semi-weighted Fatar keyboard with 3.5 octaves
Channel (mono) aftertouch with bipolar amount
Freely assignable mod destinations
Clock:
Master clock with tap tempo
BPM control and display
MIDI clock synchronisation
Arpeggiator:
Selectable note value: 16th note, 8th triplet, 8th note, dotted 8th note, quarter note
One, two or three octaves range
Up, down, up/down, random and assignment mode
Sequencer:
Polyphonic step sequencer with up to 64 steps, including ties and rests
Effects:
Stereo analogue overdrive
Two 24-bit 48 kHz digital effects, including Reverb (room, hall, plate and spring reverb), delay (full-bandwidth digital delay and emulated bucket brigade), chorus, flanger, Oberheim phase shifter and ring modulator emulations
Delay tempo synchronisation
True Bypass ensures a completely analogue signal path when the digital effects are switched off
Performance features:
Hold function
Polyphonic portamento
Unison mode (monophonic) with configurable number of voices, from one to all five voices, and button modes to control the priority of voice triggering
Preset memory:
256 user and 256 factory programmes in 32 banks of 16 programmes each
Direct programme access, including one-button access to the current set of 16 programmes
Connections:
Audio outputs left/mono and right (2 x 6.3 mm jack)
Headphone output (stereo, 6.3 mm jack)
5-pin MIDI input, output and thru
USB for bidirectional MIDI communication
Pedal connection (6.3mm jack)
Sustain foot pedal connection (6.3mm jack)
Physical specifications:
Dimensions: 63.5 cm x 32.4 cm x 11.2 cm
Weight: 7.7 kg
The Oberheim legacy is yours: TEO-5.
Thomas Elroy Oberheim. TEO. More than just his initials, they mark the culmination of a synthesiser pioneer's vision. The TEO-5 is a modern instrument with classic analogue sound generation, yet elegant and powerful for the sonic demands of today.
Welcome to the Oberheim Renaissance
TEO-5 captures the secrets of the OB-X, Four Voice and TVS, their legendary spirit brought into a compact, affordable dream factory. It's what Tom, the maestro himself, always wanted to build: a timeless sound palette, unadulterated and accessible.
Step up to the TEO-5
Take your music to the next level with real analogue VCOs and VCFs. The TEO's five inspiring voices sing with the warmth and power of pure triangle, sawtooth and pulse waves. But this is not your grandfather's synthesiser. Updated oscillators work with analogue through-zero FM to bring out textures never heard before. It's organic and raw, ready to be processed with the legendary SEM filter, the Oberheim centrepiece that beats in countless hits from the last five decades.
Modern perfection meets vintage magic
Immerse yourself in the faithful OB-8 envelope emulations of the TEO-5 and the multitude of modulations with which you can shape your sounds with pinpoint accuracy. You can then use the two digital effects chorus, delay and reverb to shape your sound. And for a taste of Oberheim's true history, dial in emulations of Tom's legendary Phase Shifter and Ring Modulator to conjure up swirling textures and metallic resonances straight out of the golden age of synthesis.
Creative and inspiring
It's not just a synthesiser, it's a playground. The TEO-5's 64-step polyphonic sequencer opens up endless melodic possibilities, while the multimode arpeggiator lets your rhythms pulse and throb. Or play live with the first-class Fatar keybed, which fills every note with a responsive joy of playing. From soaring leads to cascading chords to thundering basses, TEO-5 will enhance every aspect of your musical performance.
The TEO-5 is your sonic passport - from the studio to the stage. A gateway to the Oberheim heritage and an affordable introduction to your hobby. Whether you're a seasoned pro looking for a compact powerhouse or a new artist starting your analogue adventure, TEO-5 invites you in.
It's Tom Oberheim's dream come true. It's your sonic legacy waiting to be written.
Welcome to the TEO-5.
Properties
| Aftertouch: | Yes |
|---|---|
| Number of buttons: | 44 |
| Polyphony: | 5 |
| Sound generation: | Analogue |
