Monacor CTG-1NOISE
€35.48
Prices incl. VAT plus shipping costs
(Free shipping from 49,-€ order value within Germany)
In stock
XLR function tester, 48 V
with integrated pink noise generator
For quick and easy functional testing of balanced microphone cables or microphone inputs on stage
Visual error message via LED:
2x flashing: Pin 2 of the XLR cable is defective
3x flashing: Pin 3 of the XLR cable is defective
LED is off: Pin 1 or phantom power is defective
LED lights up permanently: cable is faultless, noise generator
Technical data:
3-pin XLR connector
Power supply via phantom power 9-48 V
Output amplitude 100 mVpp
Dimensions Ø 19 mm x 74 mm
Weight 31 g
Do you know the situation? The microphone on stage is not sending a signal to the FOH position and you need to find the fault. Is it the microphone or the cable? Is it the multicore or the console channel? You don't have an ohmmeter to hand or the battery in it is flat.
The MONACOR solution: Simply plug the CTG into the microphone cable, switch on the phantom power and the tester will show you the fault. The CTG is available with a pink noise generator (-1NOISE), a white noise generator (-1WNOISE) or with a 100 Hz sine wave generator (-1SINE).
