Mipro ACT-717-H59

Set consisting of:

1 x ACT-717B receiver

1 x ACT-72H handheld transmitter with MU-59 dynamic microphone head

Frequency range: 823-832 MHz (8AD) registration-free (centre gap)

Features ACT-717B receiver:

EIA standard 1/2 19" RU (ACT - 717B ) & 19" RU ( ACT-727B/747B ) robust heat-dissipating metal housing with perfect shielding against interference.

UHF PLL synthesiser with high stability and low spurious emissions.

3rd generation Mipro: Improved RF filter elements and circuits for lower sensitivity to interference signals and more interference-free channels.

104 preset channels in 10 groups together with the auto-scan function enable a quick search for interference-free channels.

The world's first ACT™ (Automatic Channel Targeting) offers precise and fast frequency synchronisation between receiver and transmitters.

True diversity antenna system for best reception quality.

Dual squelch setting for NoiseLock and pilot tone. Transmitter can be switched on/off at any time without causing disturbing noise.

The bright colour VFD (vacuum fluorescent display), unique in the industry, offers a wide viewing angle on the crystal-clear display of all parameters. Automatic dimming of the display in stand-by mode.

All settings can be made quickly and intuitively using a single rotary knob.

Adjustment of the reception sensitivity via the interference warning display. Higher sensitivity for a wider reception range, lower sensitivity to reduce interference.

Output signal can be tapped as a single or sum signal, adjustable in 3 stages. The output level is matched to the sensitivity of the microphone capsule and ensures optimum performance.

TNC antenna connections with 8V power supply (e.g. for optional boosters)

PC control software for real-time control and monitoring.

Internal switching power supply for a stable power supply of 100 ~ 240V AC .

Features: ACT-72H hand-held transmitter with MU-59 dynamic microphone head:

Elegant design in basic sterling grey.

Operation with 2 x AA batteries

Quick and easy replacement of the 2 AA batteries/rechargeable batteries by unscrewing the microphone head and the handle cover.

Interchangeable head system for quick and easy conversion of the microphone heads to premium condenser or dynamic capsules.

The unique multi-piece metal grille protects the capsule from shocks, makes it insensitive to popping noises and ensures clear sound.

LCD display with indication of battery status, group and channel.

Input sensitivity of the microphone capsule adjustable in five steps from +6bB to -18dB.

Mute function of the handheld transmitter can be preset.

Optional transmission power high/low.

Integrated high-performance antenna, on/off button, mute button, setup buttons for setting the microphone sensitivity, the limiter, the low-cut function and the transmission power are compactly located in the lower part of the housing.

Plug-on caps with different colour markings for assigning channels to the respective users for larger setups.
