Lehle P-Split III

The LEHLE P-SPLIT III stands for passive splitting with maximum signal fidelity.

The possible applications range from splitting and eliminating hum to balancing, reamping and recording applications.

At the heart of the LEHLE P-SPLIT III is the LEHLE TRANSFORMER HZ, which galvanically isolates the two outputs, allowing you to successfully avoid ground loops and hum. The LEHLE TRANSFORMER HZ was specially designed for use with high-impedance signals, but it also splits low-impedance signals with uncompromising sound quality. The signal can be tapped either balanced or unbalanced at the ISO output. A gold-plated phase reversal switch allows you to rotate the phase of the output signal at the ISO output, which prevents phase cancellations from negatively affecting the reproduction of the signal.

The classic application of the LEHLE P-SPLIT III is splitting an input signal to the two outputs. This allows you to connect one instrument to two devices. These can be two amplifiers, for example, or an amplifier and a mixing console or recording unit (audio interface/DAW). Thanks to the option of tapping the signal symmetrically at the ISO output, the LEHLE P-SPLIT III is also excellently suited as a high-quality and compact DI box for all types of signals.

Another useful application for the LEHLE P-SPLIT III is the effective elimination of unwanted humming noises. Connecting two electronic devices can result in background noise caused by ground loops. The LEHLE P-SPLIT III offers a simple but extremely effective solution here by being connected between the two devices. The versatile splitter can also be used as a passive mono summing device for stereo signals by using the DIR output as a second input. By using the ISO output, the devices are galvanically isolated and background noise is a thing of the past. By the way, if you are looking for a power connection: The LEHLE P-SPLIT III does not require any power supply.
