IK Multimedia iLoud MTM MK2 Immersive Bundle

Type: 2-way/3-speaker bi-amped, digitally controlled studio monitor

LF driver: 2 x 3.5 composite cellulose fibre mid-woofers, custom-made

HF driver: 1 low-distortion silk dome tweeter with rear chambers

Acoustic design: DSP-tuned bass reflex

Number of amplifiers per speaker: 2

Amplifier type: High-efficiency Class-D

Total power: 100 W RMS

LF power: 70 W RMS

HF power: 30 W RMS

Crossover type: Digital, linear phase

Crossover frequency: 2.8 kHz

Frequency response: 48 Hz to 28 kHz +/- 2dB, 36 Hz to 32 kHz @ -10dB

Phase response: System remains coherent within +/- 15° from 200 Hz to 20 kHz

Sensitivity at +4 dBu: -6 dBu signal generates 94 dB SPL @ 1 m

Sensitivity at -10 dBV: -17 dBu signal generates 94 dB SPL at 1 m distance

Continuous maximum sound pressure level: 97 dB (free field, one speaker, 1 m distance, ANSI-2034 weighted pink noise)

Peak SPL: 110.5 dB (free field, one speaker, 1 m distance, ANSI-2034 weighted pink noise)

Peak SPL: 112.5 dB (half-space, one speaker, 1 m distance, ANSI-2034 weighted pink noise)

Placement adjustment: Manual switches for LF extension, LF trim, HF trim, console position

LF extension switch: Sets the -3dB point of the frequency response at 40, 50, 60 or 80 Hz (LFE)

LF switch: Low shelf, +2 dB or -3 dB from 100 Hz downwards

HF switch: High frequency range, +2 dB or -3 dB from 8 kHz upwards

Desk switch: -4 dB at 160 Hz and +1 dB at 1.8 kHz

Calibration: Fully automatic and integrated digital calibration

Full DSP control

X-MONITOR macOS and Windows control software

Total latency (TOF): 2.44 ms

Connections: 1 x Combo XLR, TRS balanced input, 1 x 1/8 TS ARC microphone input, 1 x USB Type-B, AC

POWER socket

Power requirement: 90 to 240 V AC, auto-ranging, 50 or 60 Hz, 120 W maximum power consumption

Dimensions: 264 mm (10.39") x 160 mm (6.3") x 130 mm (5.12")

Weight: 2.5 kg (5.50 lb.) including tilt base

Scope of delivery:

11x iLoud MTM MKII monitor, mains cable, 1x ARC measurement microphone with connection cable and microphone clamp, feet for horizontal positioning, locking key
