Eurolite QuickDMX radio receiver phantom-powered

Article-No 1144495

Eurolite QuickDMX radio receiver phantom-powered

€89.00*

Prices incl. VAT plus shipping costs

Finanzieren Sie bequem mit Consors Finanz.
Weitere Informationen finden sie hier.

Cheaper elsewhere?

In stock

Eurolite QuickDMX radio receiver phantom-powered

Compact DMX radio receiver 2.4 GHz, phantom-powered

DMX radio receiver in miniature format for wireless transmission of up to 512 DMX channels

User-friendly 5-pin XLR connector (female) with swivelling antenna

Wireless DMX eliminates the need for complex cabling between the DMX controller and the DMX-controlled devices in lighting systems

GFSK modulation with 78 channels means interference-free operation, even alongside other QuickDMX receivers and other wireless devices in the 2.4 GHz band (such as W-LAN and Bluetooth)

Range up to 400 metres

1 to 512 QuickDMX receivers can be operated per transmitter

Plug & Play: Quick and easy commissioning with a button for connecting/disconnecting QuickDMX receivers

LED function indicator

Transceiver, can be used as transmitter and receiver

Requires 5 V phantom power for operation

2.4 GHz ISM band - registration and fee-free worldwide

Control: QuickDMX built-in; DMX

Technical details:

Power supply: 5 V DC

Protection class: IP20

Power connection: Power supply 5-pin XLR (W) add-on version

DMX channels: Input 512

DMX output: 1 x 5-pin XLR (W)

Control: QuickDMX built-in, DMX

Colour: Silver

Modulation: GFSK

Parallel operation: max. 6 transmitters

Range: 400 m

Carrier frequency: 2.4 GHz

Length: 21.2 cm

Diameter: 1.8 cm

Weight: 0.10 kg

Eurolite

Contact:

Steinigke Showtechnic GmbH
Andreas-Bauer-Str. 5
97297 Waldbüttelbrunn

E-Mail: info@steinigke.de
Web: https://www.steinigke.de/

Eurolite is an established manufacturer of lighting and effects technology, specialising in providing innovative solutions for the event and entertainment industry. Based in Germany, Eurolite offers a wide range of products including spotlights, LED lighting systems, fog machines and control technology suitable for both professional and semi-professional applications. The company places great emphasis on quality and user-friendliness and combines modern technology with creative designs to produce impressive lighting effects. Eurolite has made a name for itself by offering reliable and cost-effective products that are appreciated by DJs, bands, event organisers and theatre production alike. Through continuous innovation, Eurolite remains a major player in the field of lighting technology, helping to make events of all kinds shine.
