ESI planet 22x
€474.33
Prices incl. VAT plus shipping costs
(Free shipping from 49,-€ order value within Germany)
Delivery in 3-6 days
Dante network audio interface with 2 analogue input and 2 analogue output channels
2 balanced XLR/jack combo inputs
2 balanced XLR outputs
high-quality 24-bit / 96kHz AD converter with 118dB(a) dynamic range
high-quality 24-bit / 96kHz DA converter with 123dB(a) dynamic range
professional low-noise microphone preamplifier switchable per channel with adjustable gain
+48V phantom power for connected microphones
high-quality Hi-Z instrument input stage switchable per channel
precise step potentiometer for controlling the master level via the line output
high-quality adjustable headphone output
12V DC power supply included
Power supply via network cable possible (PoE / Power over Ethernet)
Dante Virtual Soundcard licence for Mac / PC included
supports Windows 7, Windows 8.1 and Windows 10 with WDM and ASIO 2.0
supports macOS with CoreAudio
Deckadance LE licence (from Stanton) included
Bitwig Studio 8-track digital audio workstation software included
inTone 2 ESI Edition licence from Audified included
Dimensions: approx. 17.5cm x 12.0cm x 4.5cm
planet 22x is a revolutionary new audio interface that combines state-of-the-art network audio technology based on the Dante protocol with the requirements of a professional high-end audio interface for the music studio and for mobile use.
The audio interface features high-quality 24-bit / 96kHz AD converters with 118dB(a) dynamic range and 24-bit / 96kHz DA converters with 123dB(a) dynamic range. If required, the two balanced analogue line inputs can also be used with the integrated ultra-clean microphone preamps or via a high-quality Hi-Z input stage for instruments. The two balanced analogue line outputs can be adjusted via a high-quality step potentiometer for the master level. An extremely high-quality headphone amplifier is also available.
planet 22x is supplied with power either via the supplied 12V DC power supply unit or via the power supply cable using PoE (Power over Ethernet). It can therefore also be used when there is no power socket nearby.
Thanks to Dante support, planet 22x works with all other Dante-compatible audio devices in the Audio-IP network: this makes it an extremely cost-effective way of expanding an existing network with additional high-quality channels and also a flexible professional audio interface together with the Dante Virtual Soundcard for all common recording applications on Mac and PC in a professional studio environment.
