Article-No 1136125

DPA 4061-OC-C-F10

€583.10*

Prices incl. VAT plus shipping costs

Finanzieren Sie bequem mit Consors Finanz.
Weitere Informationen finden sie hier.

In stock

DPA 4061-OC-C-F10

Directional characteristic: Omnidirectional

Operating principle: Pressure

Capsule type: Pre-polarised condenser element with vertical diaphragm

Frequency range, +/-2 dB: Soft Boost Grid: 20 Hz - 20 kHz, 3 dB soft boost at 8-20 kHz. High Boost Grid: 20 Hz - 20 kHz, 10 dB boost at 12 kHz

Sensitivity, nominal, +/-3 dB at 1 kHz: 6 mV / Pa; -44 DB re. 1 V / Pa

Equivalent noise level A-weighted: Typ. 26 dB (A) re. 20 & mgr; Pa (max. 28 dB (A))

Equiv. noise level ITU-R BS.468-4: Typ. 38 dB (40 dB max.)

S / N ratio, re. 1 kHz at 1 Pa (94 dB SPL): 68 dB (A)

Total harmonic distortion (THD): <1% THD up to 123 dB SPL peak; <1% THD up to 120 dB SPL RMS sine wave

Dynamic range: Typ. 97 dB

Max. SPL, peaks before clipping: 144 dB

Output impedance: 30 - 40 Ohm

Cable drive capability: up to 300 m (984 ft)

Power supply: For wireless systems: Min. 5 V - max. 50 V via DPA adapter. With DAD6001-BC / DAD6024 / DAD4099: 48 V phantom power ± 4 V for full power.

Connection: TA4F female

Colour: Beige

Operating temperature range: -40 ° C to 45 ° C (-40 ° F to 113 ° F)

Relative humidity (RF): Up to 90%

Microphone diameter: 5.4 mm

Microphone length: max. 12.7 mm

Cable length: 1.8 m

Cable diameter: 1.6 mm

Weight: 7.5 g


The DPA 4061-OC-C-F10 microphone was originally developed for use with wireless systems in theatre, television and instrument applications with close mics and is extremely unobtrusive. Due to its small size, it has an extremely accurate omnidirectional pattern and therefore does not need to be pointed directly at the sound source to achieve a high quality recording. The d: screet ™ CORE 4061 for Loud SPL increases the THD and dynamic range by 14 dB.
