Chauvet DJ CoDot ILS
€257.05
Prices incl. VAT plus shipping costs
(Free shipping from 49,-€ order value within Germany)
Weitere Informationen finden sie hier.
In stock
LED lighting in coin format for small applications where conventional lights do not fit
Includes two lens options to fulfil different application criteria
Magnetic base for easy attachment to metal surfaces
Threaded insert is compatible with camera tripods and accessories
ILS compatibility for use in the ILS ecosystem
Built-in DFI transceiver transmits DMX or ILS signals wirelessly
Built-in RF receiver for wireless control with the optional RFC or RFC-XL remote controls
Easy navigation and access to all functions directly via the LED display
Power supply for multiple devices via the USB Type-C input and output
DMX channels: 4 or 6
Light source: 1 LED (four-colour RGBW) 3 W, (0.8 A), 50,000 hours life expectancy
Strobe rate: 0 to 20 Hz
PWM frequency: 1200 Hz
Beam angle (installed lens): 19°
Beam angle (lens supplied): 14°
Illuminance (installed lens): 256 lux @ 2 m
Illuminance (incl. lens): 442 lux @ 2 m
Maximum unobstructed distance: 183 m (600 ft)
Operating frequency: 2.4 GHz
Power link: 4 units at 120 V; 4 units at 230 V
Input voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and current: 7 W, 0.1 A at 120 V, 60 Hz
Optional control units: : 7 W, 0.1 A at 230 V, 50 Hz
Weight: 0.1 kg
Size: 57x54x24 mm
Optional control units: ILS-Commandl, RFC, RFC-XL
Approvals: CE, ROHS, UKCA, FCC
Scope of delivery:
4x CoDot ILS
8x lenses
3x short USB cables (0.5m)
3x long USB cables (2 m)
Carrying case
external plug-in power supply
With CoDot ILS, party lighting fits in the palm of your hand. This puck-sized LED lighting is the perfect solution for small spaces where traditional lights won't fit. Each CoDot ILS features 1 four-colour (RGBW) LED that is suitable for a range of applications. Thanks to D-Fi, ILS and RF compatibility, this spotlight can be operated with the lighting control that best suits your needs. Light up any area of your venue with CoDot ILS.
Properties
| Colour mixing: | RGBW |
|---|---|
| Number of LEDs: | 1 |
| Power per LED: | 3 W |
| Remote control: | optional |
Product video
