BSS AR-133
€128.70*
Prices incl. VAT plus shipping costs
Weitere Informationen finden sie hier.
In stock
Battery/phantom
XLR/KLI in
KLI-Link - XLR out
Output-gnd-lift
PAD -20/40 dB
galvanic isolation
The input is designed both as an unbalanced jack socket and as an XLR socket with a jack loop-through output. The PAD switch not only activates an input attenuation of 20 or 40 dB, but also changes the input impedance: while in the 0 dB position 1 Mohm allows the problem-free and low-loss connection of high-impedance guitar or bass pickups, the impedance at -20 and -40 dB is 47 kOhm. The XLR output is transformer-balanced for load impedances of 600 ohms or higher.
Power can be supplied via a 9V battery (<2mA) or phantom power (20 - 48V, <8mA), whereby switching to phantom power can also be automated. The special shape allows cables to be bundled underneath the housing grounding.
Active DI box with XLR and jack input with a jack loop-through output, PAD switch for 20 and 40 dB input level reduction and switching of the input impedance between 1 MOhm (0 dB) and 47 kOhm (-20/-40 dB), transformer-balanced XLR output for load impedances of at least 600 Ohm. Power supply either via 9V block battery or phantom power, manually or automatically switchable. Shock-resistant, domed housing with rubber corners. The AR-133 from BSS or equivalent is recommended.
