Bricasti Design M7

100 unique reverb presets

Revolutionary new reverb algorithms

Real stereo reverb processor

Classic & new presets: Halls, Plates, Rooms, Chambers & Ambient Spaces

100 user registers

4 front panel favourites for quick saving and comparison

Hardware design:

Dual power supply technology

Specially developed linear transformer power supply for the analogue range

High-performance switching power supply for the digital range

Separate analogue and digital modules

Stainless steel chassis and cover

Specially machined aluminium knobs and aluminium front panel

Detented potentiometer for the analogue input level (2dB steps)

MIDI I/O

"Hand crafted in the USA

Digital section - features & performance:

AES 24 bit digital I/O

AES Single Wire 192kHz

Self-clocking against external clock rates from 44.1 kHz to 192 kHz

6 Dual-Core Analog Devices DSPs

Analogue section - features & performance:

Jitter < 20 picoseconds

Input level adjustable in 2dB steps

Analogue I/O on XLR balanced

24 bit conversion

Dual D/A

Fully balanced analogue input and output circuits (DC-coupled)

Update:

The Bricasti M7 reverb processor and the M10 Remote are now supplied with the new software version V2. An update (EPROM) for M7 devices with V1 will be available free of charge in exchange for the V1 EPROMs (the exchanged EPROMs must be returned). The update can also be carried out at Mega Audio (recommended for M10 Remote) for a service fee of €45 plus shipping.

The new, downward-compatible software offers a variety of new features while retaining the simple operation and control of the V1 functions:

A "Larger than Life" reverb algorithm (V2) with associated new presets

New delay and modulation parameters available in both the V1 and V2 algorithms and presets

An expanded selection of early reverbs, available for V1 and V2 algorithms

New presets for V1 and V2 algorithms plus non-linear presets

Extended MIDI functionality with selective SysEx dumps

Mute and bypass function

The new presets and programme banks:

All original V1 presets remain unchanged from the original release. Additional presets in the banks that are based on the original algorithm and some that also use the new delay parameters are available for V1 and V2.

The V2 presets are presented in a whole series of new banks labelled Halls 2, Rooms 2, Plates 2 and Spaces 2. These presets are based on the new V2 algorithm and have the same parameters as the V1 presets, including delay. M7 users will find their way around very quickly after an upgrade.

A third algorithm is labelled "Non Linear" and is based on the classic AMS RMX 16. This comparatively simple algorithm only uses the parameters Rolloff, Size, Early Select, Early Balance and Early Rolloff.

New V2 algorithm:

The new V2 algorithm is based on some components of the V1 version, so the clarity and airiness, the natural density and the operation are retained. The Early Reverb with the new selection of settings and the VLF (Very Low Frequency) Reverb have been adopted unchanged from V1. The main change compared to V1 is the Late Reverb, which brings a completely new sound with more colouration. Significantly more effect, but without losing the high-resolution, clear density for which the V1 presets are so well known.

The editing parameters and operation remain unchanged under V2, so there is no need for a second familiarisation period after an upgrade. In isolated cases, a parameter change may have a different effect on the sound than usual because the underlying algorithm has changed. The key parameters that have a different character are Modulation, Reverb Rolloff Filter, Diffusion and Density.

Extended MIDI functionality:

Software version 2 brings many new MIDI features such as programme change and selective SysEx dump. Program changes can be assigned to preset programs by bank, user registers and favourites. Furthermore, system settings, user registers and favourites can be exchanged directly between two M7s via MIDI link.
