Acoustic Line i4

The TS 100 2-way full-range speaker is designed for many applications with a rated power handling of 150W / RMS. Thanks to its discreet appearance and excellent sound characteristics, the speaker, which weighs just 7.1 kilograms, is equally suitable for entertainment installations in bistros, clubs and restaurants or AV applications in conference rooms, trade fairs and hotels, for example, but also as front fill in theatres. Together with a PowerSub 312, for example, the TS 100 forms an extremely compact, lightweight and powerful PA system. The nominal impedance of 16 ohms makes it possible to operate up to eight TS 100s on one power amplifier channel. A low-distortion DND 6130-16 neodymium chassis is used for the bass and mid-range; the high-frequency range is covered by a Constant Directivity HPT94 tweeter horn, which can be easily rotated by 90 degrees for horizontal applications. Brilliant high-frequency reproduction is guaranteed by the Electro-Voice DH3 driver.

Powerful and universal mid-high range system with classic 2 x 8" Nd / 1" drivers. Well suited as a powerful top unit in combination with subwoofers and as a stand-alone system for speech transmission over short and medium distances. Four M10 mounting points (optionally five when replacing the factory-fitted HS flange socket) in combination with the accessories enable simple installation in horizontal and vertical alignment.

The AMM108 multipurpose speaker features a passive, coaxial two-way design with a 1.7-inch compression driver and an 8-inch low-frequency driver and a peak SPL of 128 dB. Bose's proprietary Beamwidth Matching Waveguide technology delivers Bose's unmistakable sound quality, characterised by consistently clear reproduction with uniform frequency response across the entire sound reinforcement range. The result is an outstanding sound experience for artists and audiences alike. The AMM108 is equally suitable for various sound reinforcement, monitor and installation applications over medium distances in fixed installations or portable PA sound systems and offers outstanding clarity of vocal reproduction. The sound reproduction of the AMM108 matches the Bose AM array modules and the Bose AMU utility speakers, so you can easily combine models from all three ranges to create different systems.

Various external, passive additional loudspeakers are available for the MA 808, MA 708, MA 707 and MA 705 models to improve the spatial sound effect. All additional loudspeakers have a stand flange and come with a 10 m connection cable.

Huge LF voice coils:The Titan 12Z features a massive 3" LF voice coil.This efficient voice coil helps to deliver the massive 132dB Max SPL that the 12Z is capable of.Manufactured in-house by Wharfedale Pro, this LF component also utilises a rigid steel basket to ensure smooth delivery of mids and lows with minimal mechanical distortion.Familiar design:The Titan 12Z utilises the same proven cabinet design as the Titan X12.By using an organically moulded polypropylene enclosure with an internal laminar flow rib pattern, not only is a powerful and acoustically flawless speaker created, but the speaker is also highly portable. This is suitable for applications such as mobile DJs, bands and public address.The trapezoidal design also allows the 12Z to be placed on the floor and used as a stage monitor.The Titan 12Z also has multiple mounting options. With 10 x M8 threads and an integrated 35mm flange, the Titan 12Z can be easily installed in any environment.IRIS X compression driver technology:The coil size and electrical sensitivity of a speaker transducer are critical to its performance. Titan Z speakers now incorporate our proprietary IRIS X design, which offers increased coil radius and electrical sensitivity. The coil radius ensures even heat dissipation during prolonged high-volume use, while the increased electrical sensitivity ensures that the transducer converts as much electrical power into sound power as the laws of physics allow.A hot transducer wastes energy, risks damage and distorts. IRIS X reduces this by improving heat dissipation and efficiency. In practice, IRIS X transducers deliver higher sound pressure with lower distortion. They are market-leading in specification and are designed and built entirely in Wharfedale Pro.
